GMW SRCa Series Electric Magnetic Motor Starter

FOB Reference Price:Get Latest Price
$5.00 - $100.00 / Pieces | 50 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
JUNW/OEM
Model Number:
GMW SRCa
Frequency:
50/60Hz
Color:
Black/White
Certificate:
CE ISO9001
Standard:
IEC 60947-4
Number of Pole:
3
Electricity Type:
AC
Phase:
3
Main Circuit Rating Current:
9A/12A/18A/22A/32A/40A
Main Circuit Rating Voltage:
110V/220V/380V/400V/550V
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Standard export package or OEM.
Port
Ningbo/Shanghai/Others
Lead Time :
Less than 20 days, depend on the quantity.

GMW SRCa Series Electric Magnetic Motor Starter

Application

GMW SRCa series magnetic starter is mainly applied in circuit of AC 50 or 60Hz, voltage up to 550V for far distance making and breaking circuit and frequently starting and controlling motor. It has the features of small volume, light weight, low power consumption, high efficiency, safe and reliable performance etc.

Specification

Type

Selected AC Contactor

Selected Thermal Overload Relay

Rated Power KW/HP( AC-3 )IEC60947-4-1 GB14048.4

Rated Current A(AC-3) IEC60947-4-1 GB14048.4

Rated Heating Current Ith:(A)

Rated Insulated Voltage Ui:(V)

Auxiliary Contact AC-15

Electrical/Mechanic Life (Million Times)

Contact Arrangement

Rated Current (A)(AC-3) IEC60947-4-1 GB14048.4

Rated Heating Current Ith:(A)

200-220V

380-
440V

200-220V

380-440V

Standard

Special

200-220V

380-440V

GMW-9

GMC-9

GTH-22

2.5/3.5

4/5.5

11

9

20

660

1NO+1NC

/

1.6

0.95

16

1/5

GMW-12

GMC-12

GTH-22

3.5/4.7

5.5/7.5

13

12

20

660

1NO+1NC

/

1.6

0.95

16

1/5

GMW-18

GMC-18

GTH-22

4.5/6

7.5/10

18

18

25

660

1NO+1NC

/

1.6

0.95

16

1/5

GMW-22

GMC-22

GTH-22

5.5/7.5

11/15

22

22

32

660

1NO+1NC

/

1.6

0.95

16

1/5

GMW-32

GMC-32

GTH-40

7.5/10

15/20

32

32

45

660

2NO+2NC

/

1.6

0.95

16

1/5

GMW-40

GMC-40

GTH-40

11/15

18.5/25

40

40

50



2NO+2NC



1.6

0.95

16

1/5
